AIDC Backup Power.

Designed for compatibility with modern AI data center power infrastructures, including UPS, HVDC and next-generation DC architectures.

UPS

HVDC

Next-generation DC architectures

Backup power cabinets

DP30

Backup cabinet

326kWper cabinet

Footprint per cabinet0.48m²

Backup duration10 – 30min

DP60

Backup cabinet

630kWper cabinet

Footprint per cabinet0.48m²

Backup duration5 – 10min

DP54

Backup cabinet

630kWper cabinet

Footprint per cabinet0.57m²

Backup duration5 – 10min

WZN100Z01

Backup cabinet

336kWper cabinet

Footprint per cabinet0.66m²

Backup duration5 – 10min

Select a product to view its technical specifications

DP30 technical specifications

LFP system for AI data centers

326kW

Maximum discharge power

10 – 30min

Backup power duration

0.48m²

Footprint per cabinet

IP20

Protection rating

ItemSpecification

Electrochemical systemLFP

Rated voltage (Vdc)614.4

Rated capacity (Ah)120

Rated energy (kWh)73.7

Number of battery modules12

Number of high-voltage boxes1

Voltage range (Vdc)518.4 ~ 681.6

Maximum operating temperatureCharging 0°C to 40°C; Discharge −20°C to 40°C

Recommended ambient temperature15°C ~ 35°C

ItemSpecification

Cooling methodAir cooling

Battery module type51.2V 120Ah (1P16S)

Dimensions600 × 800 × 2000 mm

Weight (±3%)860 kg

Parallel capabilitySupports up to 16 cabinets in parallel

Storage temperature−20°C ~ 45°C

Altitude0–4000 m; above 2500 m, use 3%/500 m derating

Humidity5% ~ 95% RH

DP60 technical specifications

LFP system for AI data centers

630kW

Maximum discharge power

5 – 10min

Backup power duration

0.48m²

Footprint per cabinet

10C

Discharge rating

ItemSpecification

Electrochemical systemLFP

Rated voltage (Vdc)614.4

Rated capacity (Ah)125

Rated energy (kWh)76.8

Number of battery modules12

Number of high-voltage boxes1

Voltage range (Vdc)518.4 ~ 681.6

Maximum operating temperatureCharging 0°C to 40°C; Discharge −20°C to 40°C

Recommended ambient temperature15°C ~ 35°C

ItemSpecification

Cooling methodAir cooling

Battery module type51.2V 125Ah

Dimensions600 × 800 × 2000 mm

Weight (±3%)1230 kg

Parallel capabilitySupports up to 16 cabinets in parallel

Storage temperature−20°C ~ 45°C

Altitude0–4000 m; above 2500 m, use 3%/500 m derating

Humidity5% ~ 95% RH

DP54 technical specifications

IMM-Shield immersion-cooled battery

630kW

Maximum discharge power

5 – 10min

Backup power duration

0.57m²

Footprint per cabinet

IP67

Protection rating

Patented

Coolant

UL9540A

Certification

ItemSpecification

Electrochemical systemLFP

Rated voltage (Vdc)640

Rated capacity (Ah)120

Rated energy (kWh)76.8

Number of battery modules10

Number of high-voltage boxes1

Voltage range (Vdc)540 ~ 710

Maximum operating temperatureCharging 0°C to 40°C; Discharge −20°C to 40°C

Recommended ambient temperature15°C ~ 35°C

ItemSpecification

Cooling methodLiquid cooling

Battery module type64V 120Ah

Dimensions600 × 950 × 2300 mm

Weight (±3%)1235 kg

Parallel capabilitySupports up to 16 cabinets in parallel

Storage temperature−20°C ~ 45°C

Altitude0–4000 m; above 2500 m, use 3%/500 m derating

Humidity5% ~ 95% RH

WZN100Z01 technical specifications

Aqueous zinc-ion battery system

90Ah

Rated capacity

IP20

Protection rating

Ni–Zn

Nickel–zinc battery with an aqueous electrolyte

ItemSpecification

Electrochemical systemNickel–zinc, aqueous electrolyte

Nominal voltage (Vdc)554.4

Charging voltage range (Vdc)420 ~ 638.4

Standard charging current (A)50

Nominal energy storage (kWh)41.6

Backup duration10 min @ 250 kW; 5 min @ 336 kW discharge

Number of battery modules42

Battery module type13.2V 90Ah

MonitoringBMS manages charging and continuously monitors voltage, temperature and current during discharge and standby

ItemSpecification

Communication interfacesRS485, CAN, LAN, dry contacts, Ethernet port

Communication protocolsModbus TCP/RTU, CAN2.0B

Operating temperature range20°C ~ 35°C

Storage temperature range−20°C ~ 50°C

Humidity range5% ~ 95% RH

Cooling methodNatural cooling

Dimensions (W × D × H)600 × 1100 × 2000 mm

Weight (kg)800
